Kalibrating Mashines SC
PETKUS Calibrating Systems provide for a precise sorting of the required calibers and are variable with regard to the number of calibers whereby up to five different calibers can be sorted in one screening. PETKUS offers a wide and variable range of different hole sizes for slotted and round-hole screens.
Characteristics
-
Low specific screen load due to two screen compartments and up to six screen layers and a working width of up to 1500 mm
-
ompartments and up to six screen layers and a working width of up to 1500 mm Up to five different sizes in one screening
-
Variable infeed system for handling several different products
-
Proven ball cleaning method minimizes the danger of clogging by equally dispersing the material over the entire working surface
-
Efficient inlet dust removal
SC 124 | SC 154 | SC 126 | SC 156 | ||
---|---|---|---|---|---|
Length | (mm) | 2605 | 3605 | 4149 | 4227 |
Width | (mm) | 850 | 850 | 950 | 1150 |
Height | (mm) | 1995 | 1995 | 2160 | 2600 |
Weight | (kg) | 600 | 600 | 700 | 900 |
